SKU:
CN VIORI124838120
€ 292,84
1-2 weeks delivery time
-
+
The Victron Orion-Tr Smart 12/48-8A (ORI124838120) is a powerful isolated DC-DC charger designed to convert 12V input to 48V output with a continuous 8A current at 360W power. Featuring full Bluetooth programmability, adaptive 3-stage charging, and galvanic isolation, it’s ideal for integrating 48V lithium or lead-acid battery banks into 12V systems in marine, mobile, and industrial environments. Dimensions: 130 × 186 × 80 mm; Weight: 1.8 kg.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 12/48-8A Isolated DC-DC Charger – 360W
The Victron Orion-Tr Smart 12/48-8A (ORI124838120) is an advanced isolated DC-DC charger optimized for systems where 48V battery banks must be charged from a 12V power source. Delivering 8A of output current at 48.2V and up to 360W of power, it features Bluetooth configuration, a smart adaptive 3-stage charge algorithm, and full galvanic isolation. This unit is perfect for battery-to-battery charging in campervans, boats, and off-grid systems.
Technical Specifications Model Orion-Tr Smart 12/48-8A (ORI124838120) Input Voltage Range 8 – 17 VDC Nominal Output Voltage 48.2 VDC Adjustable Output Voltage 40 – 60 VDC Continuous Output Current @ 40°C 8 A Peak Output Current (10 s) 15 A Short Circuit Output Current 25 A Continuous Output Power @ 25°C 430 W Continuous Output Power @ 40°C 360 W Efficiency 89% Galvanic Isolation 200 VDC (input/output/case) Bluetooth Configuration Yes (via VictronConnect app) Charging Algorithm Adaptive 3-stage or fixed voltage Remote On/Off Control Yes (2-pole terminal) Standby Current < 1 mA Protection Class IP43 (electronics), IP22 (terminal area) Dimensions (H × W × D) 130 × 186 × 80 mm Weight 1.8 kg Connection Type Screw terminals (up to 16 mm² / AWG6) Certifications EN 60950, EN 61000, ECE R10-5
Key Features
- DC-DC charger from 12V to 48V with 8A output
- Full Bluetooth configuration via VictronConnect
- Adaptive 3-stage charging or fixed voltage mode
- Supports smart alternators (Euro 5/6)
- Fully isolated for safety and compatibility
Protection Features
- Over-temperature and short-circuit protection
- Reverse polarity and over-voltage protection
- Parallel-capable for higher current requirements
Applications
- Charging 48V lithium or lead-acid batteries from 12V alternators
- Off-grid solar battery banks with 12V starter sources
- Mobile systems with mixed-voltage DC setups
- Electric marine systems and battery-to-battery charging
Documents
Victron Energy Orion-Tr Smart DC-DC Charger Isolated Size: 353,6 Kb -
