Victron Energy CMP122200000 - MultiPlus Compact 12/2000/80-30 230V VE.Bus

Victron Energy CMP122200000 - MultiPlus Compact 12/2000/80-30 230V VE.Bus

Key Features:

• Combines a powerful inverter and battery charger in a compact design, ideal for off-grid and backup applications.
• PowerControl and PowerAssist technology to prevent overloads and boost power from limited AC sources like shore or generator power.
• Parallel operation capability, allowing up to six units for increased power output, and three-phase configuration for added flexibility.
• Two AC outputs, including an uninterrupted output for critical loads in case of grid failure.
• Remote monitoring and control options available via the Victron Remote Management (VRM) platform and GX devices.
• Compatible with VE.Bus for seamless integration into larger energy systems and easy system configuration.

Specifications:

• Continuous Output Power: 2000 VA (1600W at 25°C), 1400W at 40°C
• Peak Power: 4000W
• Input Voltage Range: 9.5 - 17V DC
• Inverter Output Voltage: 230 VAC ± 2%, Frequency: 50 Hz ± 0.1%
• Charger Output: 80A max with adaptive charging for efficient battery management
• Transfer Switch: 30A
• Maximum Efficiency: Up to 94%
• Operating Temperature Range: -40°C to +65°C with fan-assisted cooling
• Protection Features: Short circuit, overload, high/low battery voltage, high temperature, and input voltage ripple protection
• Connectivity: VE.Bus port for parallel and three-phase operation, remote monitoring, and system integration
• Remote On/Off and Programmable Relay: Supports remote management and alarms
• Dimensions: 20.5 x 10.1 x 4.9 inches (520 x 255 x 125 mm)
• Weight: 10 kg
• Certifications: EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1, EN 55014-1, and more

Compatibility and Application:

• Perfect for off-grid and backup applications, especially where a compact and versatile inverter/charger solution is needed.
• Ideal for use in marine, RV, and industrial environments, supporting integration with VE.Bus systems for larger energy setups.

Benefits:

• Ensures uninterrupted power for critical loads with rapid transfer switching during grid outages.
• Offers flexibility and scalability with parallel and three-phase capability to adapt to expanding energy needs.
• Allows remote control and monitoring for ease of management in off-grid, mobile, and industrial setups.
