Victron Energy CMP121800000 - MultiPlus Compact 12/800/35-16 230V VE.Bus Inverter/Charger

SKU: CN VICMP121800000

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus Compact 12/800/35-16 is a compact all-in-one inverter and charger system for 12V battery setups, offering 800VA (700W) of continuous pure sine wave AC output and a 35A adaptive charger. Featuring PowerAssist and PowerControl for intelligent AC load management, as well as VE.Bus for remote monitoring and integration, this unit is ideal for mobile, marine, and off-grid systems that require efficient and reliable power delivery in a minimal footprint.

Description
Ask a Question

Victron MultiPlus Compact 12/800/35-16 Inverter/Charger (CMP121800000)

The Victron MultiPlus Compact CMP121800000 combines a true sine wave inverter, a sophisticated battery charger, and a high-speed AC transfer switch into one compact unit. Designed for 12V battery systems, it delivers 800VA (700W continuous) of clean 230V AC power and offers a 35A adaptive charger. This model is ideal for small-scale off-grid, mobile, and marine energy setups where space is limited but reliability is essential.

Key Features:

800VA Pure Sine Wave Inverter: Stable 230V AC output for sensitive electronics and appliances.
35A Intelligent Battery Charger: 4-stage adaptive charging ensures optimal battery health and fast recovery.
PowerAssist: Prevents overload by boosting shore or generator power with battery support.
PowerControl: Dynamically manages AC input to avoid overloading external sources.
High-Speed Transfer Switch: Switches to inverter in under 20 milliseconds for uninterrupted operation.
VE.Bus Communication: Enables remote monitoring and parallel/3-phase configuration with GX devices.
Compact & Lightweight: Easy to install in tight spaces with minimal wiring.

Technical Specifications:

Specification	Value
Model Number	CMP121800000
Battery Voltage	12 V
Inverter Power	800 VA / 700 W continuous
Peak Power	1600 W
Output Voltage / Frequency	230 V ±2% / 50 Hz ±0.1%
Charger Current	35 A
Absorption / Float Voltage	14.4 V / 13.8 V
Transfer Switch Rating	16 A
AC Input Voltage Range	187–265 VAC
Max Efficiency	92%
No Load Consumption	8–10 W
Dimensions (H x W x D)	375 x 214 x 110 mm
Weight	10 kg
Enclosure	Aluminium, IP21

Integration & Monitoring:

VE.Bus: For connecting to Cerbo GX, Digital Multi Control, or VE.Bus Smart Dongle.
Remote Access: Full monitoring and control via Victron VRM Portal and VictronConnect app.
Parallel / 3-Phase Support: Expandable power systems via parallel and three-phase operation.

Typical Applications:

Marine vessels and yachts
RVs, campervans, and expedition vehicles
Off-grid solar and backup systems
Small business or remote site energy systems

The Victron MultiPlus Compact 12/800/35-16 offers an efficient and reliable power solution in a small form factor—ideal for systems where space, performance, and flexibility are all critical.
