The Victron Energy MEGA-Fuse 400A/80V is engineered for the most power-intensive 80V DC circuits. With a massive 400A current rating, cold resistance of just 0.128 mΩ, and low voltage drop of 80 mV, this fuse ensures efficient and rapid fault disconnection with minimal energy loss. Supplied in a 5-pack, it is ideal for use in high-capacity battery systems, marine propulsion, and heavy-duty renewable installations.
- Description
- Ask a Question
-
Victron Energy MEGA-Fuse 400A/80V (Pack of 5)
The Victron Energy MEGA-Fuse 400A/80V is built to protect high-current DC systems from overloads and short circuits, while maintaining optimal electrical efficiency. With its robust 400 amp capacity and low internal resistance, it is a critical component in high-demand energy architectures.
Technical Specifications
Attribute Value Rated Current 400 A Rated Voltage 80 V DC Cold Resistance 0.128 mΩ Approx. Voltage Drop 80 mV Quantity in Pack 5 pieces Fuse Type MEGA
Key Features
- Extremely high current capacity: 400A at 80V DC
- Ultra-low internal resistance for reduced energy waste
- Quick response to overcurrent events
- Designed for industrial-grade applications
- Delivered in packs of 5 for efficient deployment
Applications
- High-output marine power systems
- Large battery banks and energy storage
- DC propulsion and heavy-duty inverters
- Off-grid and renewable energy systems
The Victron MEGA-Fuse 400A/80V is a top-tier protection solution where performance, reliability, and safety are paramount in extreme-current applications.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
