€ 42,64
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron Energy MEGA-Fuse 125A/80V is built for demanding DC circuits operating up to 80 volts and delivering up to 125 amps of current. With a cold resistance of 0.653 mΩ and an approximate voltage drop of 110 mV, this fuse delivers fast and efficient overcurrent interruption without unnecessary power loss. Designed for marine, off-grid, and industrial systems, this model comes in a practical 5-piece pack to support both new installations and long-term maintenance needs.
- Description
- Ask a Question
-
Victron Energy MEGA-Fuse 125A/80V (Pack of 5)
The Victron Energy MEGA-Fuse 125A/80V offers rugged overcurrent protection for high-capacity DC systems up to 80V. Engineered to handle substantial loads with speed and precision, it ensures that critical components remain safe from overcurrent events while maintaining system efficiency.
Technical Specifications
Attribute Value Rated Current 125 A Rated Voltage 80 V DC Cold Resistance 0.653 mΩ Approx. Voltage Drop 110 mV Quantity in Pack 5 pieces Fuse Type MEGA
Key Features
- 125A rated capacity for robust energy systems
- Low internal resistance reduces heat and energy loss
- Stable operation at up to 80V DC
- Quick-response protection during overloads or faults
- Supplied in cost-effective packs of 5
Applications
- Marine and electric propulsion systems
- Industrial battery and DC bus protection
- Off-grid solar and hybrid power setups
- Heavy-duty automotive and renewable energy equipment
Built to meet professional demands, the Victron MEGA-Fuse 125A/80V delivers both protection and performance where it matters most.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
