The Victron MIDI-Fuse 50A/58V (CIP133050010) is a bolt-on blade-type DC protection fuse designed specifically for 48V systems. Rated at 50A and 58VDC, it offers fast and reliable circuit interruption with a low cold resistance of 1.0 mΩ and typical voltage drop of 65 mV. Ideal for protecting mid-current DC circuits in mobile, solar, and industrial energy systems. Sold individually.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 50A/58V (1 pc) – High-Voltage DC Protection Fuse for 48V Systems
The Victron MIDI-Fuse 50A/58V is a high-quality overcurrent fuse optimized for 48VDC systems. With a compact bolt-on design and robust 50A rating, it ensures safe protection for distribution circuits, inverters, and battery connections. The low internal resistance and minimal voltage drop improve system efficiency while maintaining excellent thermal stability.
Main Features
- Rated current: 50 A
- Maximum system voltage: 58 VDC
- Cold resistance: 1.0 mΩ
- Typical voltage drop: 65 mV
- Form factor: MIDI (bolt-on, industry standard)
- Sold individually (1 fuse per pack)
- Compatible with Victron MIDI fuse holders and Lynx Distributor modules
Technical Specifications
Electrical Rated current 50 A Maximum voltage 58 VDC Cold resistance 1.0 mΩ Typical voltage drop 65 mV Mechanical Mounting type MIDI bolt-on Packaging 1 fuse per unit
Application Notes
- Designed for use in 48V battery banks, inverters, and DC loads
- Fits MIDI-standard fuse holders and Victron distribution modules
- Install with correct torque to ensure reliable conductivity
The Victron MIDI-Fuse 50A/58V provides precise and dependable circuit protection for high-voltage low-current DC circuits. Perfectly suited for 48V Victron systems, it helps maintain system integrity while delivering safety and performance.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
