The Victron MIDI-Fuse 40A/58V (CIP133040010) is a bolt-down DC fuse designed specifically for 48V systems, with a 40A rating and maximum operating voltage of 58VDC. Offering a cold resistance of 1.4 mΩ and a voltage drop of 65 mV, it ensures efficient and fast-acting protection in compact DC power architectures. Sold individually and compatible with standard MIDI fuse holders.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 40A/58V (1 pc) – Precision Protection Fuse for 48V Systems
The Victron MIDI-Fuse 40A/58V is a compact, bolt-on fuse rated for precise overcurrent protection in modern 48V DC systems. Built for compatibility with Victron's MIDI fuse holders and Lynx DC modules, it delivers fast response and low energy loss in sensitive medium-load applications.
Main Features
- Rated current: 40 A
- Maximum voltage: 58 VDC
- Cold resistance: 1.4 mΩ
- Typical voltage drop: 65 mV
- Form factor: MIDI (bolt-on blade fuse)
- Supplied as a single fuse (1 piece)
- Compatible with Victron MIDI fuse holders and Lynx Distributor systems
Technical Specifications
Electrical Rated current 40 A Maximum system voltage 58 VDC Cold resistance 1.4 mΩ Typical voltage drop 65 mV Mechanical Mounting type Bolt-on (MIDI standard) Packaging 1 fuse per unit
Application Notes
- Use in 48V Victron DC energy systems for control circuits or moderate power lines
- Install using compatible MIDI fuse holders with secure bolt contact
- Observe correct torque to maintain conductivity and thermal stability
The Victron MIDI-Fuse 40A/58V offers dependable protection with compact dimensions and minimal voltage loss, making it ideal for clean and efficient 48V energy systems where safety and electrical precision are critical.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
