SKU:
CN VICIP132200010
€ 11,22
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron MIDI-Fuse 200A/32V (CIP132200010) is a high-current bolt-on DC fuse rated at 200A for low-voltage systems up to 32VDC. With an internal resistance of just 0.25 mΩ and a typical voltage drop of 80 mV, it ensures effective overcurrent protection with minimal energy loss. Delivered in a pack of 5 units, it is fully compatible with standard MIDI fuse holders and Victron Lynx Distributor modules.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 200A/32V (5 pcs) – Heavy-Duty DC Circuit Protection Fuse
The Victron MIDI-Fuse 200A/32V is a compact and reliable overcurrent protection device for high-load DC applications. Its bolt-down MIDI design ensures strong electrical contact, while its low internal resistance of just 0.25 milliohms minimizes heat buildup and power loss. Ideal for protecting battery lines, inverters, and heavy-duty DC buses.
Main Features
- Rated current: 200 A
- Maximum voltage: 32 VDC
- Cold resistance: 0.25 mΩ
- Typical voltage drop: 80 mV
- Bolt-on MIDI design for secure high-current connection
- Delivered in a set of 5 pieces
- Compatible with Victron MIDI fuse holders and Lynx modules
Technical Specifications
Electrical Rated current 200 A Maximum system voltage 32 VDC Cold resistance 0.25 mΩ Typical voltage drop 80 mV Mechanical Mounting type Standard MIDI bolt-on Packaging 5 fuses per pack
Application Notes
- Protects high-current lines such as battery outputs, inverter feeds, and busbars
- For use with Victron-compatible MIDI fuse holders and distribution panels
- Ensure proper tightening torque for reliable contact and thermal performance
The Victron MIDI-Fuse 200A/32V is a heavy-duty protection fuse for demanding DC environments. It offers fast response, low resistance, and trusted compatibility with Victron systems, making it essential for safe high-current energy distribution.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
