SKU:
CN VICIP132150010
€ 11,22
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron MIDI-Fuse 150A/32V (CIP132150010) is a heavy-duty blade-type fuse rated at 150A for DC systems up to 32V. It delivers excellent low-resistance performance (0.30 mΩ) and a typical voltage drop of 80 mV, ensuring minimal energy loss under load. Packaged in sets of five, this fuse is ideal for protecting large loads like inverters, battery banks, or DC buses in Victron-based systems.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 150A/32V (5 pcs) – High-Current DC Blade Fuse
The Victron MIDI-Fuse 150A/32V is a bolt-down DC protection fuse designed for reliable overcurrent protection in energy storage, marine, and automotive systems. Its robust construction and low electrical resistance make it ideal for use with high-draw DC equipment, ensuring system stability and safety under high load conditions.
Main Features
- Rated current: 150 A
- Maximum voltage: 32 VDC
- Cold resistance: 0.30 mΩ
- Typical voltage drop: 80 mV
- Bolt-on MIDI form factor for secure installation
- Supplied in a pack of 5 units
- Compatible with Victron MIDI fuse holders and Lynx Distributor modules
Technical Specifications
Electrical Rated current 150 A Maximum voltage 32 VDC Cold resistance 0.30 mΩ Typical voltage drop 80 mV Mechanical Mounting type MIDI bolt-on fuse Packaging 5 fuses per pack
Application Notes
- Ideal for protecting high-power components such as large inverters and DC-DC converters
- To be mounted using compatible MIDI fuse holders
- Ensure proper terminal tightening to maintain performance and safety
The Victron MIDI-Fuse 150A/32V is engineered for reliability, durability, and efficiency in high-current DC environments. It ensures safe protection while maintaining low resistance and minimal voltage drop, and is a trusted choice for professional-grade power systems.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
