The Victron MIDI-Fuse 125A/32V (CIP132125010) is a bolt-on blade fuse rated at 125A and up to 32VDC. With an ultra-low cold resistance of just 0.30 mΩ and a voltage drop of approximately 60 mV, it ensures efficient and reliable protection for DC circuits in mobile, marine, and off-grid applications. Supplied in a set of 5 pieces, it is fully compatible with Victron MIDI fuse holders and Lynx Distributor modules.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 125A/32V (5 pcs) – Bolt-On DC Protection Fuse
The Victron MIDI-Fuse 125A/32V is a high-performance DC overcurrent fuse designed for bolt-mount installation in medium- to high-current systems. With extremely low internal resistance, it minimizes energy losses while providing fast protection against overloads and short circuits. Suitable for battery systems, inverter protection, and distribution boards.
Main Features
- Rated current: 125 A
- Maximum system voltage: 32 VDC
- Cold resistance: 0.30 mΩ
- Typical voltage drop: 60 mV
- MIDI standard form factor – bolt-on type
- Delivered as pack of 5 pieces
- Compatible with Victron MIDI fuse holders and Lynx systems
Technical Specifications
Electrical Rated current 125 A Maximum voltage 32 VDC Cold resistance 0.30 mΩ Typical voltage drop 60 mV Mechanical Mounting type Standard MIDI bolt-on Packaging 5 fuses per pack
Application Notes
- Recommended for use between battery banks and inverters, chargers, or busbars
- Install in MIDI fuse holders or Lynx Distributor modules
- Ensure proper contact torque and terminal surface for maximum reliability
The Victron MIDI-Fuse 125A/32V combines low electrical resistance with strong mechanical durability. It is ideal for protecting key components in energy systems where compact size, high current handling, and reliable performance are critical.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
