SKU:
CN VICIP132100010
€ 11,22
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron MIDI-Fuse 100A/32V (CIP132100010) is a compact DC circuit protection fuse rated at 100A for use in systems up to 32VDC. Featuring a low cold resistance of 0.45 mΩ and a typical voltage drop of just 60 mV, it offers fast, reliable overcurrent protection with minimal energy loss. Supplied in a pack of 5, it’s compatible with all standard MIDI fuse holders and Victron Lynx Distributor modules.
- Description
- Ask a Question
-
Victron Energy MIDI-Fuse 100A/32V (5 pcs) – High-Efficiency DC Overcurrent Protection Fuse
The Victron MIDI-Fuse 100A/32V is a high-quality bolt-down fuse designed to safeguard medium-to-high current DC circuits in 12V, 24V, or 32V systems. It ensures safe disconnection under fault conditions with a fast response time, low internal resistance, and a compact, robust form factor ideal for automotive, marine, and energy storage applications.
Main Features
- Rated current: 100 A
- Maximum system voltage: 32 VDC
- Cold resistance: 0.45 mΩ
- Typical voltage drop: 60 mV
- MIDI bolt-on format for secure connections
- Supplied in a pack of 5 pieces
- Compatible with Victron MIDI fuse holders and Lynx Distributor
Technical Specifications
Electrical Rated current 100 A Maximum voltage 32 VDC Cold resistance 0.45 mΩ Typical voltage drop 60 mV Mechanical Mounting type Standard MIDI bolt-down Packaging 5 fuses per pack
Application Notes
- Protects circuits such as inverters, DC-DC chargers, or battery outputs
- Designed for installation in MIDI fuse holders or Victron Lynx modules
- Apply correct torque for secure contact and thermal performance
The Victron MIDI-Fuse 100A/32V is a trusted, high-performance solution for protecting medium-to-high current DC lines, offering excellent reliability, minimal power loss, and perfect fit for Victron energy systems.
Documents
Victron Energy Midi, Mega and ANL-fuses, and fuse holders Size: 160,8 Kb -
