Victron CIN121220000 – Phoenix Inverter Compact 12/1200 230V VE.Bus
The Victron Energy Phoenix Inverter Compact 12/1200 is a highly efficient pure sine wave inverter engineered for professional-grade mobile, marine, and off-grid systems. With 1200VA (1000W) of continuous output power and a surge capacity of 2400W, it can reliably power a wide range of electronic equipment. The inverter employs SinusMax technology, allowing high startup current for demanding loads like compressors and power tools. The integrated VE.Bus communication port supports advanced system configuration, monitoring, and parallel or three-phase operation.
Key Features:
- Pure Sine Wave Output: Ideal for powering sensitive electronics and motor loads.
- SinusMax Technology: Provides high peak power for reliable start-up of heavy-duty equipment.
- VE.Bus Interface: Enables connection to Victron GX devices, PC software, or Bluetooth via MK3-USB adapter.
- Parallel & Three-Phase Operation: Supports advanced installations with multiple inverters.
- Programmable Relay: Can be configured for alarms, generator start/stop, and other controls.
- Energy-Saving Modes: Includes AES and Search mode to reduce no-load power consumption.
- Robust Protections: Includes short circuit, overload, over/under voltage, and high temperature protection.
Technical Specifications:
Parameter Value Model Number CIN121220000 Input Voltage 12V DC (range: 9.5 – 17V) Output Voltage / Frequency 230V ±2%, 50Hz ±0.1% (adjustable to 60Hz) Continuous Power at 25°C 1200VA / 1000W Power at 40°C / 65°C 900W / 600W Peak Power 2400W Max Efficiency 92% No-load Power Consumption 8W (Normal) / 5W (AES) / 2W (Search Mode) Programmable Relay Yes VE.Bus Communication Yes Remote On/Off Yes Cooling Fan-assisted Operating Temperature -40°C to +65°C Humidity (non-condensing) Max 95% Protection Category IP21 Enclosure Material Aluminium, Blue RAL 5012 Battery Connection 1.5m cable with M8 terminals AC Connection G-ST18i plug Dimensions (H × W × D) 375 × 214 × 110 mm Weight 10 kg
Standards & Certifications:
- Safety: EN 60335-1
- EMC: EN 55014-1 / EN 55014-2
Compatible Accessories:
- MK3-USB VE.Bus to USB Interface
- Victron GX Devices (e.g. Cerbo GX)
- Inverter Control Panel
- BMV Battery Monitor
- VE.Bus to NMEA 2000 Interface
The Victron Phoenix Inverter Compact 12/1200 offers compact dimensions, professional performance, and reliable power conversion for demanding AC loads, making it ideal for boats, vehicles, and off-grid applications.
Documents
Victron Energy Inverter Compact 1200VA - 2000VA 12:24:48V Size: 650,8 Kb -
