Victron Centaur 12/50 (3) 120/240V Battery Charger - CCH012050000

SKU: CN VICCH012050000

€ 586,81

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Victron Centaur 12/50 (3) is a heavy-duty, analog-controlled 12V battery charger that delivers 50A across three isolated outputs, each capable of providing the full rated current. Featuring universal AC (90–265V) and DC (90–400V) input, a fan-assisted cooling system, selectable 3-stage IUoU charge profiles, and internal temperature compensation, this model (437 x 239 x 110 mm, 5.0 kg) is optimized for marine, vehicle, and industrial power applications where absolute reliability is essential.

Description
Ask a Question

Victron Energy Centaur 12V 50A Battery Charger – 3 Outputs, Analog Control, 120/240V AC

The Victron Centaur 12/50 (3) is a robust, convection-cooled battery charger engineered for tough conditions and critical applications. With three fully-rated 12V outputs, this analog charger supports simultaneous charging of multiple battery banks, powered by global AC/DC input with no switching required. Built in a corrosion-resistant aluminum housing, it provides dependable charging with minimal maintenance.

Key Features:

3 Fully-Rated Outputs: Simultaneously charge three battery banks with up to 50A total current.
Universal AC/DC Input: Accepts 90–265 VAC or 90–400 VDC, 45–65 Hz, no manual switching needed.
3-Stage IUoU Charging: Bulk, Absorption (4 h timer), and Float stages for GEL, AGM, or Flooded batteries (selectable via DIP switch).
Temperature Compensation: Internal sensor adjusts charge voltage by –2 mV/°C per cell.
Rugged Enclosure: Epoxy-coated aluminum case with IP20 protection and stainless steel hardware, ideal for harsh marine or industrial environments.
Forced Fan Cooling: Automatically regulated based on internal temperature and output current.
Overheat Protection: Output is derated at elevated temperatures for continuous safe operation.

Technical Specifications:

Model	Centaur 12/50 (3)
DC Output Voltage	12 V nominal
Total Output Current	50 A
Number of Outputs	3 (fully isolated and rated)
Input Voltage (AC)	90 – 265 VAC
Input Voltage (DC)	90 – 400 VDC
Frequency	45 – 65 Hz
Power Factor	1
Charge Algorithm	IUoU (3-stage) with float; 2-stage optional
Absorption Voltage	14.3 V
Float Voltage	13.5 V
Recommended Battery Capacity	200 – 500 Ah
Battery Types Supported	Flooded, AGM, GEL
Cooling	Forced fan (temperature & current controlled)
Temperature Compensation	–2 mV/°C per cell
Enclosure	Aluminum (RAL 5012 blue), IP20
Protection Features	Short circuit, over-temperature
Operating Temperature	–20°C to +60°C (output derated above 40°C)
Humidity	Max 95% (non-condensing)
Dimensions	437 x 239 x 110 mm (17.2 x 9.4 x 4.3 in)
Weight	5.0 kg (11 lbs)
Battery Connection	M8 studs
AC Connection	Screw clamp, 4 mm² (AWG 6)
Certifications	EN 60335-1, EN 60335-2-29, UL 1236 EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3
