Victron Centaur 12/40 (3) 120/240V Battery Charger - CCH012040000

SKU: CN VICCH012040000

€ 564,37

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Victron Centaur 12/40 (3) is a heavy-duty analog-controlled charger for 12V battery systems. It delivers 40A across three isolated outputs, each capable of the full rated current, and accepts universal AC (90–265V) and DC (90–400V) input. With selectable 2- or 3-stage IUoU charging profiles, internal temperature compensation, and a rugged aluminum enclosure (437 x 239 x 110 mm, 5.0 kg), it’s ideal for marine, vehicle, and industrial installations where reliability is key.

Description
Ask a Question

Victron Energy Centaur 12V 40A Battery Charger – 3 Outputs, Analog Control, 120/240V AC

The Victron Centaur 12/40 (3) is a robust, professional-grade battery charger designed to provide uninterrupted charging performance in harsh conditions. It features three fully-rated outputs for independent charging of 12V battery banks and supports a wide range of AC and DC input voltages, making it ideal for use in global, mobile, and off-grid systems.

Key Features:

3 Isolated Outputs: Each output can supply up to 40A, allowing for charging of three battery banks simultaneously.
Universal Input: Operates from 90–265 VAC or 90–400 VDC without manual switching, fully compatible with 50/60 Hz grids.
Selectable Charge Profiles: 2-stage or 3-stage IUoU charging via DIP switch for compatibility with Flooded, AGM, and GEL batteries.
Temperature Compensation: Built-in sensor automatically adjusts voltage by –2 mV/°C per cell.
Cooling: Fan-assisted cooling system with thermal and current-based control.
Rugged Enclosure: Aluminum, epoxy-coated IP20 housing with stainless steel fittings, built for marine and industrial use.

Technical Specifications:

Model	Centaur 12/40 (3)
DC Output Voltage	12 V nominal
Total Output Current	40 A
Number of Outputs	3 (fully isolated and independently rated)
Input Voltage (AC)	90 – 265 VAC
Input Voltage (DC)	90 – 400 VDC
Input Frequency	45 – 65 Hz
Charge Algorithm	IUoU (2-stage or 3-stage selectable)
Absorption Voltage	14.3 V
Float Voltage	13.5 V
Recommended Battery Capacity	160 – 400 Ah
Battery Types Supported	Flooded, AGM, GEL
Cooling	Forced fan cooling (temp and load regulated)
Enclosure Material	Aluminum, epoxy powder coated
Protection Class	IP20
Operating Temp Range	–20°C to +60°C (derates above 40°C)
Dimensions	437 x 239 x 110 mm (17.2 x 9.4 x 4.3 in)
Weight	5.0 kg (11 lbs)
Battery Connection	M8 studs
AC Connection	Screw clamp, 4 mm² (AWG 6)
Certifications	Safety: EN 60335-1, EN 60335-2-29, UL 1236 EMC: EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3
