Victron Energy BPR065022000 - Smart Battery Protect 12/24V 65A

Article BB-BPR065022000

€ 64,42

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Victron Energy BPR065022000 - Smart Battery Protect 12/24V 65A is a vital component for safeguarding your battery systems from deep discharge, ensuring long-lasting performance and reliability. This advanced device automatically disconnects non-essential loads before the battery is fully discharged, protecting it from damage and ensuring that there is always enough power to start the engine. Featuring Bluetooth capability, the Smart Battery Protect allows for easy programming of on/off thresholds via the VictronConnect app, providing users with flexible control over their energy systems. It is compatible with both 12V and 24V systems and offers a special mode for lithium-ion batteries, enabling seamless integration with Victron's VE.Bus Battery Management System (BMS).

Description
Ask a Question

Victron Energy BPR065022000 - Smart Battery Protect 12/24V 65A

Key Features:
- Protects batteries from deep discharge by disconnecting non-essential loads before full discharge
- Automatic voltage detection for 12V and 24V systems
- Bluetooth capability for easy programming of on/off thresholds via the VictronConnect app
- Special mode for lithium-ion batteries, allowing for integration with VE.Bus BMS
- Extremely low current consumption, essential for lithium-ion battery longevity
- Overvoltage protection to prevent damage to sensitive loads
- Explosive protection through MOSFET switches, eliminating spark risks
- Delay alarm output activated when battery voltage drops below preset levels
Specifications:
- Maximum Continuous Load Current: 65A
- Peak Current (30 seconds): 250A
- Operating Voltage Range: 6-35V
- Power Consumption (Bluetooth Enabled): 1.4mA when on, 0.9mA when off or after low voltage shutdown
- Power Consumption (Bluetooth Disabled): 1.2mA when on, 0.7mA when off or after low voltage shutdown
- Alarm Output Delay: 12 seconds
- Maximum Load on Alarm Output: 50mA (short circuit proof)
- Load Disconnect Delay: 90 seconds (immediate if triggered by VE.Bus BMS)
- Load Reconnect Delay: 30 seconds
- Standard Disconnect Thresholds: 10.5V or 21V; Reconnect Thresholds: 12V or 24V
- Operating Temperature Range: Full load from -40°C to +40°C (up to 60% nominal load at 50°C)
- Weight: 0.2 kg (0.5 lbs)
- Dimensions (HxWxD): 40 x 48 x 106 mm (1.6 x 1.9 x 4.2 in)
Compatibility and Application:
- Ideal for protecting batteries in off-grid solar systems, marine applications, and automotive setups
- Enhances battery management for both lead-acid and lithium-ion batteries
- Perfect for users looking to optimize battery performance and extend battery life
Benefits:
- Prevents battery damage from deep discharge, ensuring reliable performance
- Easy programming via Bluetooth, providing user-friendly control over battery settings
- Robust design with overvoltage and explosive protection for enhanced safety
- Low power consumption minimizes impact on battery life, especially for lithium-ion systems
- Comprehensive alarm features for proactive battery management and monitoring
