Victron Blue Smart IP65 24/13 120V Charger + DC connector - BPC241331124

SKU: BB BPC241331124

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron Blue Smart IP65 24V/13A (120V) charger delivers high-performance charging for large 24V batteries in marine, RV, and industrial applications. With a 13A output and support for batteries up to 250Ah, it features adaptive 7-step charging, lithium compatibility, 0V recovery, and Bluetooth connectivity. IP65 protection and silent operation make it a durable and efficient solution for demanding off-grid environments.

Description
Ask a Question

Victron Energy BPC241331124 - Blue Smart IP65 120V Battery Charger 24V/13A + DC Connector is a powerful, fully sealed battery charger ideal for larger 24V systems. Engineered for marine, RV, and industrial power needs, it ensures optimal battery maintenance and monitoring through Bluetooth Smart connectivity and a robust charging algorithm.

Main Features:

24V charger with 13A output – recommended for batteries between 100–250Ah
Low current mode (4A) for smaller batteries or float charging
Integrated Bluetooth – manage charger settings with the VictronConnect app
Adaptive 7-stage charging: Test, Bulk, Absorption, Recondition, Float, Storage, Refresh
Automatic recovery from 0V – charges deeply discharged batteries
Battery type support: Lead-acid (AGM, GEL, Flooded) and LiFePO₄ (Lithium)
Also functions as a power supply with constant-voltage mode
Temperature-compensated charging for safe and efficient operation
IP65 protection – waterproof, dustproof, and chemical resistant

Technical Specifications:

Parameter	Value
Part Number	BPC241331124
Input Voltage	120 VAC
Input Frequency	50/60 Hz
Charge Voltage – Absorption	28.8V (Normal), 29.4V (High), 28.4V (Li-ion)
Charge Voltage – Float	27.6V (27.0V for Li-ion)
Charge Voltage – Storage	26.4V (27.0V for Li-ion)
Charge Current	13 A
Low Current Mode	4 A
Minimum Battery Voltage	0V (with auto recovery)
Efficiency	Up to 95%
Standby Power Consumption	< 0.5 W
Back Current Drain	1 mA (0.7Ah/month)
Temperature Compensation	32 mV/°C (lead-acid only)
Operating Temperature	-40°C to +60°C
Humidity	Max 95% (non-condensing)
Enclosure Rating	IP65 (dust and splash proof)
Battery Cable	1.5 m red/black with DC connector
AC Cable	1.8 m with US NEMA 1-15 plug
Dimensions (H x W x D)	60 x 105 x 190 mm
Weight	0.9 kg (2.0 lbs)
Certifications	Safety: UL 1236, CSA C22.2, EN 60335-1 / -2-29 EMC: EN 55014-1/2, EN 61000-6-3, EN 61000-6-1/2/3
