Victron LiFePO4 12.8V/100Ah NG Lithium Battery - BAT512110620

Victron Energy BAT512110620 Lithium NG Smart Battery 12.8V 100Ah (1280Wh, IP65)

The Victron BAT512110620 is a next-generation Lithium Iron Phosphate (LiFePO₄) battery from the Lithium NG series, offering 100Ah capacity at 12.8V for a total energy content of 1280Wh. Designed for long life, high efficiency, and full digital integration, this battery is ideal for off-grid, marine, industrial, and backup applications requiring maximum safety and performance.

Key Features:

• Chemistry: Lithium Iron Phosphate (LiFePO₄)
• Nominal Voltage: 12.8 V
• Capacity: 100 Ah
• Energy Content: 1280 Wh @ 25°C
• Cycle Life: 2500 @ 80% DoD, 5000 @ 50% DoD
• Cell Balancing: Integrated
• Ingress Protection: IP65 (dust-tight and water-jet resistant)
• Bluetooth: Available via BMS (not in battery)

Electrical Specifications:

• Max Continuous Discharge: 100 A
• Pulse Discharge (10s): 200 A
• End of Discharge Voltage: 11.2 V
• Max Continuous Charge: 100 A
• Pulse Charge (10s): 200 A
• Charge Voltage: 14.0 – 14.4 V
• Float Voltage: 13.5 V
• Internal Resistance: ~2 mΩ
• Round-Trip Efficiency: 92%

Mechanical & Environmental:

• Dimensions (HxWxD): 235 × 197 × 160 mm
• Weight: 9 kg
• Power Terminals: M8 threaded inserts with bolts
• BMS Interface: 50 cm cable (M8 circular male + female)
• Mounting: Upright or on side (not terminals-down), includes mounting brackets
• Operating Temp (Discharge): –20°C to +50°C
• Operating Temp (Charge): +5°C to +50°C
• Storage Temp: –45°C to +70°C
• Humidity: Max 95% (non-condensing)
• Self-Discharge Rate: ≤3% per month @ 25°C

System Integration:

• Required BMS: Lynx Smart BMS NG 500A / 1000A
• Monitoring: VictronConnect App / GX device / VRM Portal
• Battery Firmware: Auto-updated by BMS
• Max Batteries per BMS: 50 units (up to 192 kWh total for 12.8V)

Certifications:

• Cell Safety: UL1973, UL9540A, IEC62619
• Battery Performance: IEC62620 (pending)
• EMC: EN 61000-6-2 / 6-3
• Automotive: ECE R10-6 (pending)

The Victron BAT512110620 Lithium NG battery provides superior energy density, rugged construction, and intelligent control — ideal for scalable energy storage in mobile, commercial, or off-grid 12V systems.
