Victron 12V/165Ah AGM Deep Cycle Battery - BAT412151084

SKU: CN VIBAT412151084

€ 502,66

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Victron BAT412151084 is a 12V, 165Ah AGM deep cycle battery built for high-capacity, maintenance-free energy storage in demanding applications. Measuring 485 × 172 × 240 mm and weighing 47 kg, it offers 600A cold cranking amps and a 220-minute reserve capacity. With 600 cycles at 50% depth of discharge and 7–10 years float service life, it's ideal for off-grid solar, marine, telecom, and heavy-duty backup systems.

Description
Ask a Question

Victron Energy BAT412151084 12V 165Ah AGM Deep Cycle Battery

The Victron Energy BAT412151084 is a premium-grade AGM battery designed for deep-cycle operation in power-critical applications. With a large 165Ah capacity and fully sealed VRLA design, it ensures long-lasting, maintenance-free service. Engineered to deliver consistent performance under deep discharge conditions, this battery is ideal for renewable energy, telecom, backup, and industrial environments.

Key Features:
- Voltage: 12V
- Capacity: 165Ah (20hr rate at 25°C)
- Cold Cranking Amps (CCA): 600A @ 0°F
- Reserve Capacity: 220 minutes @ 80°F
- Technology: Flat-plate AGM, VRLA sealed
- Terminals: Copper
- Weight: 47 kg
- Dimensions: 485 × 172 × 240 mm
- Maintenance-free: No electrolyte refilling required
Cycle Life & Longevity:
- ~400 cycles at 80% depth of discharge
- ~600 cycles at 50% depth of discharge
- ~1500 cycles at 30% depth of discharge
- Float service life: 7–10 years at 20°C
Recommended Charging Parameters (12V System):

Charging Stage Voltage

Absorption 14.2 – 14.6 V

Float 13.5 – 13.8 V

Storage 13.2 – 13.5 V

Application Scenarios:
- Off-grid solar and wind power systems
- Industrial automation and remote control
- Marine propulsion and onboard systems
- Large UPS and telecom backup
- Emergency lighting and heavy-duty DC loads
Environmental and Usage Notes:
- Self-discharge rate: < 2% per month at 20°C
- Recommended charge current: Max 33A (0.2C)
- Temperature compensation: –24 mV/°C (12V block)
- Storage temperature: Best performance at ~20°C
With exceptional build quality and tested discharge reliability, the Victron BAT412151084 is a trusted solution for long-term power support where durability and consistent energy delivery are essential.
Documents

Victron Energy Gel and AGM Batteries Size: 377,9 Kb
