The Victron BAT412060082 is a 12V, 60Ah AGM Super Cycle battery equipped with M6 terminals and optimized for frequent deep discharges. Weighing just 14 kg and measuring 224 × 135 × 178 mm, it delivers 300A CCA and 90 minutes of reserve capacity. Ideal for portable solar setups, compact UPS systems, and remote applications requiring long cycle life and compact dimensions.
- Description
- Ask a Question
-
Victron Energy BAT412060082 12V 60Ah AGM Super Cycle Battery (M6 Terminals)
The Victron BAT412060082 is a mid-range capacity AGM Super Cycle battery designed for high-frequency deep cycling and maintenance-free operation. With its improved internal chemistry and stronger plate design, this battery excels in both mobile and stationary applications that demand a high tolerance for full discharges and consistent recharge performance. Its M6 copper terminal inserts provide secure and durable electrical connections.
Key Features:
- Voltage: 12V
- Capacity: 60Ah (C20 rate at 10.8V)
- Cold Cranking Amps (CCA): 300A @ 0°F
- Reserve Capacity: 90 minutes @ 80°F
- Terminal Type: M6 insert (copper)
- Technology: AGM Super Cycle, sealed VRLA
- Dimensions: 224 × 135 × 178 mm
- Weight: 14 kg
- Maintenance: Fully sealed, no venting or refilling required
Deep Cycle Life:
- ≥ 300 cycles @ 100% DoD
- ≥ 700 cycles @ 60% DoD
- ≥ 1000 cycles @ 40% DoD
Charging Parameters:
Charge Stage Normal Voltage Fast Recharge Voltage Absorption 14.2 – 14.6 V 14.6 – 14.9 V Float 13.5 – 13.8 V Storage 13.2 – 13.5 V
Common Applications:
- Portable solar or lighting systems
- Compact UPS and battery backup units
- Off-grid remote control or monitoring
- Electric carts, wheelchairs, and DC tools
Technical Notes:
- Self-discharge rate: Less than 2% per month at 20°C
- Temperature compensation: –24 mV/°C for 12V systems
- Charge current limit: Recommended ≤ 12A (0.2C)
Reliable, compact, and capable of withstanding extreme cycling demands, the Victron BAT412060082 is the ideal battery for off-grid energy storage systems where space, weight, and durability are critical.
Documents
Victron Energy AGM Super Cycle Battery Size: 120,5 Kb -
