Victron Energy BAT412025081 12V 25Ah AGM Super Cycle Battery (M5 Terminals)
The Victron BAT412025081 is an ultra-durable 12V AGM Super Cycle battery engineered for exceptional deep-cycle performance in compact and mobile applications. With enhanced positive plate composition and a specialized electrolyte formula, this model resists sulfation and plate softening, even under repeated 100% depth-of-discharge events. Its compact format and M5 terminal inserts make it ideal for tightly spaced enclosures and portable systems.
Key Features:
- Voltage: 12V
- Capacity: 25Ah (C20 rating at 10.8V)
- Terminal Type: M5 insert
- Technology: AGM Super Cycle (sealed VRLA)
- Dimensions: 181 × 77 × 175 mm
- Weight: 6.5 kg
- Maintenance: Fully sealed, zero-maintenance
Exceptional Cycle Performance:
- ≥ 300 cycles @ 100% DoD
- ≥ 700 cycles @ 60% DoD
- ≥ 1000 cycles @ 40% DoD
Recommended Charging Voltages:
Charge Stage Normal Voltage Fast Recharge Voltage Absorption 14.2 – 14.6 V 14.6 – 14.9 V Float 13.5 – 13.8 V 13.5 – 13.8 V Storage 13.2 – 13.5 V
Application Areas:
- Remote sensors and monitoring stations
- Portable solar-powered systems
- Mobile lighting and security devices
- Compact UPS and backup energy
Environmental & Technical Notes:
- Temperature compensation: –24 mV/°C for 12V blocks
- Self-discharge rate: < 2% per month at 20°C
- Storage time without recharge: Up to 12 months at room temperature
With superior deep discharge tolerance, compact form factor, and maintenance-free reliability, the Victron BAT412025081 is a top choice for mobile or embedded energy systems requiring frequent cycling and long-lasting performance.
Looking for a different Victron Marine Batteries? Explore our full Victron Super Cycle Batteries product range.
Documents
Victron Energy AGM Super Cycle Battery Size: 120,5 Kb -
