The Victron BAT412015080 is a 12V AGM Super Cycle battery with a 15Ah capacity and Faston 6.3 × 0.8 mm terminals. Engineered for repeated deep discharges, it supports up to 300 full 100% DoD cycles and delivers excellent performance in compact backup, control, and monitoring systems. Measuring just 151 × 100 × 103 mm and weighing 4.1 kg, it's ideal for space-constrained installations where longevity and deep cycling matter.

Description
Ask a Question

Victron Energy BAT412015080 12V 15Ah AGM Super Cycle Battery (Faston 6.3 × 0.8 mm)

The Victron BAT412015080 is a compact, sealed VRLA AGM Super Cycle battery designed to deliver superior performance in frequent deep-discharge applications. Thanks to enhanced electrochemical composition and internal paste reinforcement, this battery excels at handling up to 100% depth-of-discharge cycles with minimal degradation, making it an ideal solution for lightweight backup, instrumentation, and small-scale solar systems.

Key Features:
- Voltage: 12V
- Capacity: 15Ah (C20 rating at 10.8V)
- Terminal Type: Faston 6.3 × 0.8 mm flat blade
- Technology: AGM Super Cycle (sealed VRLA)
- Dimensions: 151 × 100 × 103 mm
- Weight: 4.1 kg
- Maintenance: Fully sealed, maintenance-free
Exceptional Deep Discharge Endurance:
- ≥ 300 cycles @ 100% DoD (to 10.8V, 0.2C₂₀, 2h rest, then recharge)
- ≥ 700 cycles @ 60% DoD (3h discharge at 0.2C₂₀, then recharge)
- ≥ 1000 cycles @ 40% DoD (2h discharge at 0.2C₂₀, then recharge)
Recommended Charging Parameters:

Charge Stage Normal Voltage Fast Recharge Voltage

Absorption 14.2 – 14.6 V 14.6 – 14.9 V

Float 13.5 – 13.8 V 13.5 – 13.8 V

Storage 13.2 – 13.5 V

Application Scenarios:
- Remote monitoring equipment
- Small-scale solar or mobile power banks
- Security or automation devices
- Control and telemetry enclosures
Environmental Notes:
- Temperature compensation: –24 mV/°C for 12V systems
- Self-discharge: < 2% per month at 20°C
- Storage duration without charging: Up to 1 year at 20°C
With an advanced AGM design optimized for extreme cycling and compact system integration, the Victron BAT412015080 is the ideal choice for systems requiring small form factor, long cycle life, and maintenance-free operation.
