The Victron ArgoFET 100-2 is a high-efficiency dual battery isolator using FET technology to eliminate voltage drop during charge distribution. With a 100A current rating and support for both 12V and 24V systems, it enables safe, simultaneous charging of two battery banks from a single alternator or battery charger. It includes a current-limited alternator energize input and comes in a rugged 65 x 120 x 200 mm housing with M8 bolt terminals.
- Description
- Ask a Question
-
Victron Energy ArgoFET 100-2 Dual Battery Isolator, 100A, 12/24V with Alternator Energize Input
The Victron ArgoFET 100-2 battery isolator offers cutting-edge performance by using field-effect transistors (FETs) instead of diodes, resulting in extremely low voltage drop — less than 0.02 V at low current and approximately 0.1 V at higher loads. It allows two batteries to be charged independently from a single alternator without any electrical connection between the banks, and without compromising on voltage efficiency. Perfect for marine, RV, and industrial use.
Parameter Specification Model ArgoFET 100-2 Nominal Battery Voltage 12V / 24V Maximum Charge Current 100 A Maximum Alternator Current 100 A Number of Battery Outputs 2 Connection Type M8 Bolts Alternator Energize Input Yes (current-limited) Voltage Drop <0.02 V (low current), ~0.1 V (high current) Dimensions (H x W x D) 65 x 120 x 200 mm Weight 1.4 kg (3.1 lbs)
Key Features:
- FET-based technology with minimal voltage loss.
- Allows charging of two batteries from one alternator or charger.
- No need for charge voltage compensation due to low drop.
- Current-limited alternator energize input ensures startup compatibility.
- Heavy-duty terminals (M8) and compact form factor.
- Ideal for high-efficiency marine and mobile power systems.
Use Case Examples:
- Marine vessels requiring lossless dual battery isolation.
- RV systems with house and starter battery banks.
- Off-grid power setups with centralized charging infrastructure.
Documents
Victron Energy Argofet Battery Isolators Size: 139,5 Kb -
