VDO 323-801-018-001D - Oil Temperature Sender 200°C – 1/8-27 NPTF

Article VDO.323801018001D

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The VDO 323-801-018-001D oil temperature sender measures temperatures from +50°C to +200°C and operates with a 1/8-27 NPTF thread. It features a sensor length of 10.5 mm, a diameter of 8.4 mm, and requires a torque of 10 Nm. Suitable for mediums such as coolant, water, air, engine oil, transmission oil, and fuel, it supports a voltage range of 6 - 24 V DC and a resistor range of 482.5 - 14.3 Ohms, without a warning contact. Its operating temperature ranges from +170°C to +250°C.

Description
Ask a Question

VDO 323-801-018-001D - Oil Temperature Sender 200°C – 1/8-27 NPTF

The VDO 323-801-018-001D oil temperature sender is designed for precise temperature measurement in a range from +50°C to +200°C. It features a robust build with a thread size of 1/8-27 NPTF and a sensor element that extends 10.5 mm in length. The sensor has a diameter of 8.4 mm and operates optimally with a torque of 10 Nm. This sender is compatible with various temperature mediums including coolant, water, air, engine oil, transmission oil, and fuel.

For electrical specifications, the device supports an operating voltage of 6 - 24 V DC with a resistor range from 482.5 to 14.3 Ohms. It provides a single-pole common ground signal and does not include a warning contact. Its minimum to maximum operating temperature ranges from +170°C to +250°C, making it versatile for different applications.
