VDO 230-112-001-001C - Pressure switch 1.00 Bar - M10

SKU: VDO 230112001001C

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The VDO 230-112-001-001C Pressure Switch is a high-quality component designed for precise pressure monitoring in automotive and industrial systems. With a pressure setpoint of 1.00 Bar ± 0.20 Bar, it offers reliable performance across a wide range of applications, including oil, fuel, and air systems. The switch features a durable M10 x 1 conical short thread for easy installation and can withstand pressures up to 30 Bar for short durations. With an operating temperature range from -25°C to +120°C and a slow contact response, this pressure switch ensures accurate measurements and efficient operation under various conditions. Suitable for use in engine monitoring and pressure control systems, the VDO 230-112-001-001C is built to deliver long-lasting, dependable performance.

Description
Ask a Question

VDO 230-112-001-001C - Pressure Switch 1.00 Bar - M10

Key Features:
- Pressure switch with a setpoint of 1.00 Bar ± 0.20 Bar
- Thread size: M10 x 1 Conical short with a length of 26 mm
- Contact closes as pressure rises, making it ideal for engine monitoring
- Pressure range from 0 to 12 Bar, with a maximum pressure of 30 Bar for 2 seconds
- Operating temperature range: –25 °C to +120°C
- Maximum switching capacity: 5 Watts (non-inductive)
- Electrical operating voltage: 6 - 24 V DC
- Compatible with oil, fuel, and air as pressure mediums
Specifications:
- Part Number: VDO 230-112-001-001C
- Pressure switchpoint: 1.00 Bar ± 0.20 Bar
- Pressure range: 0 - 12 Bar
- Maximum pressure: 30 Bar for 2 seconds
- Switch type: 1-pole common ground
- Switching capacity: 5 Watt (maximum)
- Thread: M10 x 1 Conical short
- Thread length (L2): 11 mm
- Thread + nut length (L1): 26 mm
- Torque: 30 Nm
- Operating temperature: –25 °C to +120°C
- Housing: Hex 27 mm with a vented contact chamber
- Connector type: M4 Screw
- Operating voltage: 6 - 24 Volt DC
- Contact response: Slow
- Pressure medium: Oil, fuel, air
- Country of origin: Germany
Compatibility and Application:
- Ideal for engine monitoring and pressure monitoring applications
- Compatible with oil, fuel, and air systems
- Used in a wide range of automotive and industrial pressure systems
Benefits:
- Accurate pressure measurement with a reliable 1.00 Bar switchpoint
- Durable construction ensures long-lasting performance even under high pressures
- Wide operating temperature range allows for use in diverse environments
- Fast response time makes it suitable for dynamic systems
- Easy to install with M10 x 1 threaded connection and M4 screw connector
- Offers high switching capacity and efficiency for reliable performance
