VDO 224-082-007-004X - Ø54mm Fuel Tubular Sender 372.5mm

Article VDO.224082007004X

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The VDO 224-082-007-004X is a fuel tubular sender with a tube length of 372.5 mm, designed for tanks with a minimum depth of 376.5 mm. It features a 5-hole SAE 54 mm mounting flange, operates within temperatures of -25 °C to +65 °C, and is suitable for oil, petroleum, diesel, and gasoline. The sender supports 6 - 24 V DC with an empty resistance of 65.7 Ohm ± 2.3 Ohm and a full resistance of 1.0 Ohm ± 1.0 Ohm.

Description
Ask a Question

VDO 224-082-007-004X - Ø54mm Fuel Tubular Sender 372.5mm

Discover the VDO 224-082-007-004X, a precision-engineered fuel tubular sender designed to meet high standards of reliability and performance. This component is essential for accurate fuel level measurements in a variety of applications.

The sender features a tube length of 372.5 mm with a tolerance of ± 2.0 mm and requires a minimum tank depth of 372.5 mm ± 2.0 mm plus an additional 4.0 mm. It is equipped with a 5-hole SAE 54 mm mounting flange and operates efficiently within a temperature range of -25 °C to +65 °C.

Compatible with multiple fuel types including oil, petroleum, diesel, and gasoline, the sender supports an operating voltage range of 6 - 24 V DC. Its electrical characteristics include a resistance of 65.7 Ohm ± 2.3 Ohm when empty and 1.0 Ohm ± 1.0 Ohm when full, ensuring precise measurement accuracy.
