The Samlex LIR-250 Battery Split Relay microprocessor-controlled relay links two batteries in parallel when charging voltage is present, disconnects when voltage drops, features almost zero voltage drop, and supports easy installation.
- Description
- Ask a Question
-
Samlex LIR-250 - Battery Split Relay
The LIR-250 is a microprocessor-controlled relay designed to manage two-battery systems, ideal for boats, motorhomes, and caravans. It automatically links batteries in parallel when one battery’s voltage indicates charging, and disconnects them when voltage falls, preventing discharge. It offers a superior alternative to traditional battery isolators with almost zero voltage drop, eliminating the need to raise alternator or charger output voltage. Installation is simple and requires no changes to existing wiring.
- Order number: 00711106
- Supplier code: 83621
- Barcode: 8718013836210
- Battery voltage: Autodetects 12V or 24V (9–36 Volt range)
- Continuous power rating: 500 A
- Peak current: 2000 A for 250 milliseconds
- Power consumption off: 12V/1.8mA, 24V/2.0mA
- Power consumption on: 12V/160mA, 24V/100mA
- Battery connections: M8 and Faston 6.3mm
- Minimum battery cable thickness: 50mm²
-
