Mastervolt 43310602 - EasyCharge Battery Charger 6A - UK plug

Article Mastervolt - 43310602

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Mastervolt 43310602 EasyCharge Battery Charger 6A is a high-performance, waterproof battery charger designed for reliable and efficient charging in harsh environments. With its IP68 rating, it is built to withstand exposure to water, salt, shock, and vibration, making it perfect for marine, RV, and off-grid applications. This charger features a Mastervolt 3-step+ charging characteristic, ensuring optimal charging for Gel, AGM, and flooded batteries. It is capable of charging a single battery bank and offers full power up to 40°C. With a universal input range (120-230V) and international certifications, the EasyCharge 6A is suitable for worldwide use. Its compact and durable design, along with advanced safety features such as short circuit and reverse polarity protection, make it a reliable choice for users who require efficient and safe battery charging in challenging conditions.

Description
Ask a Question

Mastervolt 43310602 - EasyCharge Battery Charger 6A

Key Features:
- Entry-level model with Mastervolt 3-step+ charge characteristic.
- Suitable for charging Gel, AGM, and flooded batteries.
- Full power up to 40 °C for reliable performance.
- Quick charging function to extend battery life.
- Includes cable and Euro plug (optional UK plug available).
- Can charge one battery bank with series and parallel configuration options.
- Stain resistant and fully waterproof (IP68 rated) for harsh environments.
- International certification for global use.
Specifications:
- Total charge current: 6 A at 12 V
- Recommended battery capacity (charge, based on 50% discharged battery): Up to 120 Ah
- Nominal input voltage: 120/230 V (90-265 V), 50/60 Hz
- AC connection: 1.2 m (4 ft) cable + Euro plug
- DC connection: Ring terminals
- Galvanic isolation: Yes
- Dimensions (hxwxd): 76 x 152 x 51 mm (3.0 x 6.0 x 2.0 inches)
- Weight: 1.8 kg (4.0 lb)
- Compliance: CE, ABYC
- Optional UK plug available (product code: 43310602)
Technical Specifications:
- Charge characteristic: IUoUo, automatic 3-step+ for Gel/AGM/flooded batteries
- Temperature range (ambient temp.): -20 °C to 50 °C (-4 to 122 °F)
- Protection degree: IP68
- Protections: Spark-free, short circuit, reverse polarity, over voltage, current limited, over temperature
- MasterBus compatible: No
Compatibility and Application:
- Designed for use in harsh environments, including marine, RV, and off-grid applications.
- Suitable for charging a single battery bank in applications requiring reliable and efficient charging.
- Perfect for wet, AGM, and Gel batteries, providing flexibility for different types of battery configurations.
Benefits:
- Reliable and efficient charging in challenging conditions with waterproof (IP68) and shock-resistant design.
- Fast charging function extends battery life, ensuring more consistent performance.
- Global compatibility with universal input voltage (120-230 V), making it ideal for use worldwide.
- Safety features including protection against short circuits, reverse polarity, and over voltage ensure peace of mind during operation.
- Compact design with easy installation and long-lasting durability for both recreational and professional users.
