The BEP 185060P-01-1 is a 60 Amp panel mount thermal breaker with a visible reset indicator, 30V DC rating, IP67 waterproof protection, and certified for ignition protection, suitable for vehicle and marine applications.
- Description
- Ask a Question
-
BEP 185060P-01-1 - 185 Series Switchable Thermal Circuit Breaker Waterproof Panel Mount 60 Amp
Designed for auxiliary and accessory circuits in vehicles and marine applications, this 185 Series panel mount thermal breaker features a visible reset indicator and superior sealing for harsh conditions.
- Voltage rating: 30V DC
- Interrupt capacity: 3000A
- Operating temperature: -32°C to 82°C (-25°F to 180°F)
- Storage temperature range: -34°C to 149°C (-30°F to 300°F)
- Thermoset plastic housing rated UL 94VO and 155°C
- Mounting: panel or surface
- Maximum terminal stud torque: 50 in-lb (5.6Nm)
- Unique reset mechanism provides visible trip indication
- Ingress protection: IP67
- Certified to SAEJ1625, J1171, and UL1500 ignition protection
- Order number: 00599164
- Supplier code: 185060P-01-1
- Barcode: 185060P-01-1
- Fuse rating: 60 Amp
-
