SKU:
ALP 70356
€ 1.024,02
1-2 weeks delivery time
-
+
The Lofrans Windlass Horizontal, Model 'Dorado', 6mm, 12V, 500W, is designed for smaller boats (20-35 feet). With a 500W motor, it provides reliable performance with a maximum linear load of 630kg and a lift load capacity of 345kg.
- Description
- Ask a Question
-
Lofrans Windlass Horizontal, Model 'Dorado', 6mm, 12v, 500w, Without Drum
The Lofrans Windlass Horizontal 'Dorado' is ideal for smaller boats ranging from 20-35 feet (6-11m). It is powered by a 500W 12V motor and provides reliable performance without the drum for a lighter setup.
- Article number: 70356
- EAN number: 8719182093763
- For: Boats 20-35' (6-11m)
- Motor: 500W
- Power Supply: 12V
- Max. Linear Load: 630kg
- Max. Lift Load: 345kg
- Lift Working Load: 95kg
- Amps Work Load: 60A
- Line Speed: 23m/min
- Max. Line Speed: 25m/min
- Weight: 10kg
- Control box: Included
- Size: 6mm
- Conform: ISO 4565 / DIN 766
- Dimension A: 130mm
- Dimension C: 150mm
- Dimension F: 200mm
- Dimension J: Ø82mm
- Dimension L: 48mm
- Dimension M: 98mm
- Dimension N: 53mm
-
