SKU:
CN QBABR12+
€ 470,13
1-2 weeks delivery time
-
+
The Quick RRC R12+ Receiver is a versatile and efficient communication device that supports a wide voltage range from 10.5V to 31V DC. It features microcontroller-operated functions, FSK modulation at 869.8 MHz, and operates within a temperature range of -15°C to +70°C. The receiver includes LED and seven-segment displays for system status and error indication, with protection against polarity inversion and low battery. It can store up to 50 transmitters and allows multiple receivers to be controlled by a single transmitter. It also features a programmable digital filter and complies with the 2014/53/EU directive.
- Description
- Ask a Question
-
Quick RRC R12+ Receiver
The Quick RRC R12+ Receiver is a versatile and reliable product designed to meet your communication needs with high efficiency. Here are the key features:
- Supports a full power range from 10.5V to 31V DC.
- Equipped with microcontroller-operated functions for advanced control.
- Operates with FSK modulation on a frequency of 869.8 MHz.
- Works in a wide temperature range, from -15°C to +70°C.
- Displays system status, errors, and issues via LED and seven-segment displays.
- Includes protection against polarity inversion and low battery.
- Capable of storing up to 50 transmitters.
- Features translation mode for controlling multiple receivers from a single transmitter.
- Programmable digital filter for optimized signal processing.
- Option to connect an external antenna for improved range and performance.
- Compliant with directive 2014/53/EU (RED).
Technical Specifications:
- Receiver Type: R12+
- Number of Channels: 12
- Switching Capacity: 15A
- Weight: 315g
-
