SKU:
CN QALPT700R
€ 1.475,81
1-2 weeks delivery time
-
+
The Quick PTR 700 DC Capstan is built for boats with limited space but still offers high performance for marine tasks. Constructed with AISI 316 stainless steel and anodized aluminium, it is designed to handle tough conditions. Featuring a 250 W motor at 12V, it offers a maximum pull of 600 kg and a working load of 80 kg. The capstan can retrieve up to 30 meters of 6 mm rope, with a chain speed of up to 20.8 m/min, and can be used as a windlass or tender-recovery system.
- Description
- Ask a Question
-
Quick PTR 700 DC Capstan
The Quick PTR 700 DC Capstan is designed for boats with limited space, providing both functionality and durability. Constructed from AISI 316 stainless steel and anodized aluminium, this capstan is built to handle demanding marine tasks.
- Motor power: 250 W
- Motor supply voltage: 12 V
- Maximum pull: 600 Kg / 1323 lb
- Maximum working load: 220 Kg / 485 lb
- Working load: 80 Kg / 176 lb
- Current absorption @ working load: 23 A
- Maximum chain speed: 20.8 m/min / 68.2 ft/min
- Maximum chain speed @ working load: 18.1 m/min / 59.4 ft/min
- Weight: 10.2 Kg / 22.5 lb
- Capstan can retrieve 6 mm rope up to 30 meters long
- IP66 watertight motor for enhanced protection in various marine conditions
- Available in windlass version with optional bow-roller or in tender-recovery version with reel for flat straps with snap-hook
-
