€ 1.519,06
1-2 weeks delivery time
-
+
The Quick PTR 1000 DC Capstan provides a reliable anchoring and tender recovery solution for boats. Constructed from AISI 316 stainless steel and anodized aluminium, it is built to endure tough marine conditions. Powered by a 350 W motor at 24V, it can pull up to 750 kg with a working load of 100 kg. This capstan supports a maximum chain speed of 21.5 m/min and is ideal for use as either a windlass or a tender-recovery system with an optional bow-roller.
- Description
- Ask a Question
-
Quick PTR 1000 DC Capstan
The Quick PTR 1000 DC Capstan offers a reliable solution for anchoring and tender recovery on boats. Made from AISI 316 stainless steel and anodized aluminium, it combines durability and functionality for a variety of marine applications.
- Motor power: 350 W
- Motor supply voltage: 24 V
- Maximum pull: 750 Kg / 1653 lb
- Maximum working load: 250 Kg / 551 lb
- Working load: 100 Kg / 220 lb
- Current absorption @ working load: 15 A
- Maximum chain speed: 21.5 m/min / 70.5 ft/min
- Maximum chain speed @ working load: 18.3 m/min / 60 ft/min
- Weight: 10.2 Kg / 22.5 lb
- Capstan can retrieve 6 mm rope up to 30 meters long
- IP66 watertight motor for protection against harsh conditions
- Suitable for use as a windlass or tender-recovery system
- Available in windlass version with optional bow-roller or in tender-recovery version with reel for flat straps with snap-hook
-
