SKU:
CN QALPT1000G
€ 1.851,70
1-2 weeks delivery time
-
+
The Quick PTG 1000 is a compact and versatile capstan designed for various marine applications. Built with AISI 316 stainless steel and anodized aluminium, it is engineered to handle harsh marine environments. It features a 24V motor with a maximum pull of 750 kg and can be used for boats ranging from 8 to 12 meters. With a working load of 100 kg, it offers a maximum chain speed of 21.5 m/min and is suitable for tasks such as fishing or lifting tenders onboard yachts.
- Description
- Ask a Question
-
Quick PTG 1000 Multipurpose Capstan
The Quick PTG 1000 is a versatile and compact capstan designed for a variety of marine uses. Constructed from durable AISI 316 stainless steel and anodized aluminium, this capstan is built to withstand harsh marine environments.
- Voltage: 24V
- For boats: 8-12 meters
- Motor power: 350 W
- Motor supply voltage: 24 V
- Maximum pull: 750 Kg / 1653 lb
- Maximum working load: 250 Kg / 551 lb
- Working load: 100 Kg / 220 lb
- Current absorption @ working load: 16 A
- Maximum chain speed: 21.5 m/min / 70.5 ft/min
- Maximum chain speed @ working load: 18.3 m/min / 60 ft/min
- Weight: 10.2 Kg / 22.5 lb
- Capstan can retrieve strip 48 mm wide and up to 7.5 m long
- Can be used as a fishing capstan or for lifting tenders onboard yachts
- Windlass version with optional bow-roller available on request
- Designed for easy installation, either above or below the deck
-
