Lofrans SX2 Anchor Windlasses for Boats 6-13 m, Chain 8 mm

$ 2.396,32

1-2 weeks delivery time

Diameter, mm:

Voltage:

Electric power, W:

1000
1500

Item:

Without drum
With drum

The Lofrans SX2 Vertical Windlass is engineered for boats from 7.5 to 13 meters (25–45 ft). Built with AISI 316L stainless steel and a compact round base design, it provides reliable anchor handling with 1000W (12V) or 1500W (24V) motors. Available in both with drum and low-profile versions, it features an IP67-rated motor, manual chain release, and a pre-installed chain counter magnet. Designed for 8 mm DIN766 chain, it delivers smooth anchoring performance with a maximum line speed of 40 m/min.

Description
Ask a Question

Lofrans SX2 Vertical Anchor Windlass – 1000W/1500W, For Boats 7.5–13 m

The Lofrans SX2 is a versatile vertical windlass designed for boats between 7.5–13 meters (25–45 ft). Built from AISI 316L marine-grade stainless steel with a compact round base, the SX2 combines durability, power, and flexibility for safe anchoring operations.

Main Features

Stainless Steel Construction: AISI 316L body ensures corrosion resistance and durability.
Compact Round Base: Space-saving design ideal for yachts and motorboats.
Available with Drum or Low Profile: Choose according to deck layout and anchoring needs.
Independent Gypsy and Drum Operation: Flexible chain and rope handling.
Manual Chain Release: Extra safety and control during anchoring.
Chain Counter Magnet: Pre-installed, ready for chain counter connection.
Heavy-Duty Motor: IP67-rated, reliable, and seawater-protected.
Optional Chain Pipe: Available separately (code 636311).

Standard Equipment

Dual direction solenoid pack
Handle
Gypsy for chain
Instruction manual (CD)

Technical Specifications – SX2

Model	Voltage	Power	Chain Size	Boat Length	Max. Linear Load	Lift Working Load	Line Speed	Weight	Drum
SX2 – 8 mm	12V	1000W	8 mm DIN766	7.5–13 m	1000 kg	150 kg	20–40 m/min	19–20 kg	With / Without
SX2 – 8 mm	24V	1500W	8 mm DIN766	7.5–13 m	1500 kg	175 kg	19–40 m/min	24–25 kg	With / Without

With its combination of compact design, powerful motor, and stainless-steel durability, the Lofrans SX2 Vertical Windlass is an ideal solution for mid-size yachts and motorboats, delivering reliable anchoring performance and long service life.
