SKU:
LNK 14655022
$ 276,17
1-2 weeks delivery time
-
+
The Dometic DCC 1224-10 is a power charging converter that transforms a 12V input into a stable 24V output with a current of 10A, delivering efficient power conversion with an 87% yield. It features galvanic isolation, pure output voltage, supports parallel operation, and is optimized for vehicle EMC, with additional inputs for toggle control and stabilization during engine start.
- Description
- Ask a Question
-
Dometic DCC 1224-10 - Perfect Power Charging Converter 10A
This model converts a 12V input into a stable 24V output with a current of 10A, offering efficient power conversion with a high yield of 87%.
- Article Number: 14655022
- Type: DC1224-10
- Input voltage: 12V
- Output voltage: 27.6 ± 0.1V
- Output current: 10A
- Voltage conversion: 12 → 24
- Yield: 87%
- Dimensions (W x H x D mm): 115 x 70 x 155
- Weight: 1.2 kg
- Features:
- Voltage converter available in 10A, 20A, or 40A versions
- High efficiency output
- Galvanic isolation
- Pure output voltage
- Supports parallel operation
- EMC optimized for vehicle applications
- Battery charging voltage with IU-characteristic
- Additional input for toggle control
- Battery and generator stabilization
- On-board voltage stabilization during engine start
-
