Quick FSBL20624FY6B00 - BL2 P 624F Y Windlass 600W 24V 6mm FF

Quick FSBL20624FY6B00 - BL2 P 624F Y Windlass 600W 24V 6mm FF

The Quick FSBL20624FY6B00 - BL2 P 624F Y Windlass is a highly adaptable horizontal windlass designed for boats ranging from 16 to 26 feet (4.87 to 7.92 meters). It operates on a 24V power supply and features a 600W motor, offering exceptional performance for anchoring operations. The windlass is optimized for rope and chain handling and comes equipped with an automatic free-fall system, ensuring swift and easy anchor deployment.

This model is compatible with a 1/4-inch (6 mm) chain and a 1/2-inch (12 mm) rope, making it versatile and suitable for different anchoring setups. The compact design allows for flexible installation, particularly at the stern of the boat, while the stainless steel AISI 316 and chromed bronze construction provide excellent durability and corrosion resistance in marine environments.

The windlass includes a rope guide device for smooth operation, and its IP67-rated watertight motor ensures protection from water damage, even in harsh conditions. Additionally, it features an anodized aluminum gearbox, contributing to its long-lasting performance.

Technical Specifications

• Motor Type: Horizontal, without drum
• Gypsy: Rope/Chain
• Power Supply: 24V
• Power: 600W
• Boat Compatibility: 16.00 - 26.00 feet (4.87 - 7.92 m)
• Gypsy Chain Size: 1/4 inch (6 mm)
• Gypsy Rope Size: 1/2 inch (12 mm)
• Chain Fall Direction: Right-hand side

Key Features

• Ideal for stern installation
• Constructed from AISI 316 stainless steel and chromed bronze for durability
• Automatic free-fall system for easy anchor deployment
• Watertight motor with IP67 protection
• Anodized aluminum gearbox for added strength
• Includes a rope guide device for smooth operation
