The Osculati 14.277.45 Orion-Tr Smart 12/24-15A is a 360 W non-isolated DC-DC charger designed to boost 12 V supply to 24.2 V output for charging auxiliary battery banks. It supports both lead-acid and lithium batteries using a programmable 3-stage charging algorithm. Input range is 10–17 V, with continuous 15 A and peak 25 A output. Integrated Bluetooth enables full control and monitoring, while engine detection allows automated operation. The unit is also parallel-connectable for increased capacity. Dimensions: 130 × 186 × 70 mm. Weight: 1.8 kg.
- Description
- Ask a Question
-
Osculati 14.277.45 – Orion-Tr Smart 12/24-15A (360W) Non-isolated DC-DC Charger
The Osculati Orion-Tr Smart 12/24-15A (item 14.277.45) is a smart step-up DC-DC charger optimized for 12 V to 24 V battery charging in dual-bank systems. With a 3-stage charging profile, this unit is compatible with both lead-acid and lithium battery technologies. It provides a 24.2 V output with 15 A continuous and 25 A peak charging current, operating from a 10–17 V input source. The charger features Bluetooth connectivity for wireless monitoring and full programmability, as well as an engine detection function for automatic activation. Multiple units can be connected in parallel to scale output power.
Item Type Input Voltage Output Voltage Max Output (A) Continuous Output (A) Dimensions (mm) Weight (kg) 14.277.45 12-24-15 10–17 V 24.2 V 25 A 15 A 130 × 186 × 70 1.8
Main Features:
- 360 W step-up DC-DC charger from 12 V to 24 V
- 3-stage programmable charging for lithium and lead-acid batteries
- Bluetooth connectivity for monitoring and configuration
- Engine detection function for smart activation
- Parallel connection possible to increase total output
- 15 A continuous, 25 A peak current output
Applications:
- Marine systems with 24 V auxiliary battery banks
- RV and mobile charging setups requiring voltage boost
- Charging 24 V lithium or AGM battery packs from 12 V alternator
- Wireless-controlled charging systems with scalable output
Documents
Osculati Catalogue 2025 - page 244 Size: 295,1 Kb -
