Osculati 14.268.26 - Victron Energy Multiplus 24/1600/40 Inverter/Charger

Osculati 14.268.26 - Victron Multiplus 24/1600/40 Inverter/Charger

The Victron Multiplus 24/1600/40 is an all-in-one power solution designed for demanding energy environments, such as yachts, RVs, and remote installations. It merges a 1600W pure sine wave inverter with a 40A intelligent charger capable of managing lithium and lead-acid battery systems. The unit supports a DC input range of 19 to 33V, tailored to 24V installations.

The advanced charger uses a 4-stage charging curve — Bulk, Absorption, Float, and Storage — to extend battery life and maximize performance. It includes an auxiliary 4A output ideal for small battery banks or starter batteries. With two AC outputs, it allows the connection of essential and non-essential loads. The second output is only active when shore or generator power is available, preventing battery drain from high-consumption devices like water heaters.

For system flexibility, this model supports parallel and three-phase operation. Up to six units can be connected in parallel, and three identical models can be configured for three-phase output. Victron’s PowerControl dynamically limits AC input current to prevent overloads, while PowerAssist bridges short-term power deficits by drawing from the battery bank. The system returns to charging mode once the peak passes.

Key Features:

• Pure sine wave inverter delivering 1600W continuous power
• Advanced 4-stage battery charger (Bulk, Absorption, Float, Storage)
• 40A main + 4A auxiliary charge output
• Compatible with lithium and lead-acid batteries
• Two AC outputs:
  • Main output always active
  • Secondary output active only with AC input
• PowerAssist – uses battery to supplement short-term AC demand
• PowerControl – limits shore/generator draw to safe levels
• Parallel operation (up to 6 units) and three-phase ready
• Rugged aluminum enclosure
• Built-in protection against:
  • Short circuit
  • Overcharging
  • Low/high battery voltage
  • High ripple frequency
  • Overheating

Technical Specifications:

*The second AC output is only active when an external AC source is available (shore or generator).
