Lewmar 69100023 is a VX1 series lightweight vertical windlass available as Gypsy Only (GO) or Gypsy and Capstan (GD), constructed from stainless steel and composite materials. It includes motor/gearbox, relay, chain drive, and chain counter sensor, excluding switch and fuse. It offers hybrid chain drive for quieter operation, IP68 rating, non-sparking motor protection, 500W motor power, and a max pull force of 675 daN, suitable for boats 8.5 to 15 meters.
- Description
- Ask a Question
-
Lewmar 69100023 - Vertical Windlass VX1 GO 8mm 12V - 500W
The VX1 series windlasses combine lightweight materials and straightforward assembly. Available as Gypsy Only (GO) or Gypsy and Capstan (GD), the deck unit comprises stainless steel and composite parts. Included are motor/gearbox, relay, chain drive, and chain counter sensor, excluding switch and fuse.
Highlights include hybrid chain drive for quieter operation, IP68 and non-sparking motor protection, worm gear transmission, and availability of multiple engine powers (500W to 1500W). Suitable for ships 8.5 to 15 meters (28 to 50 ft). VX2 and VX3 series in 24V are available on demand.
- Article Number: 76412032
- Manufacturer Number: 69100023
- Lewmar type: VX1 GO
- Power option V: 12
- Max. motor power W: 500
- Max. pull daN: 675
- Max. line speed m/min: 25
- Working load daN: 169
- Weight kg: 12.5
- Circuit breaker A: 70
- Chain DIN766 mm: 8"
-
