SKU:
CN C-AA45200000
€ 12.168,73
1-2 weeks delivery time
-
+
The Craftsman CM4.52 Diesel Engine with intercooling is designed for reliable power and durability in various applications, offering 38.9 kW/52 HP output with a turbocharged aspiration. Key features include a 105 Nm maximum torque, 4 cylinders, indirect cooling system with a heat exchanger, and an alternator providing 90 A at 12V. It also includes flexible engine mountings, a 15° max installation angle, and weighs 182 kg, with no gearbox.
- Description
- Ask a Question
-
Craftsman CM4.52 Diesel Engine, Intercooling, No Gearbox
This engine is designed for reliable power and durability in various applications. Here are the key specifications:
- Engine Type: Mitsubishi
- Output at flywheel: 38.9kW/52HP (ISO 8665/3046)
- Maximum torque: 105Nm
- Number of cylinders: 4
- Capacity: 1758 cm
- Aspiration: Turbo Charged
- Stop solenoid: Energised to stop
- Alternator: 90 A / 12V (Bosch / SEG)
- Max. installation angle: 15° (Backwards)
- Maximum revolutions: 3000 rpm
- Cooling system: Indirect, with heat exchanger
- Flexible Engine Mountings: CM type 5*
- Calorifier connection: Optional
- Exhaust diameter: ø50 mm
- Electronic protection: 10A circuit breaker
- Weight: 182 kg
- Refrigeration: Intercooling
- Gearbox: No
-
