SKU:
BP 201-012-FB-B
$ 808,25
1-2 weeks delivery time
-
+
The Lopolight 201-012-FB-B features a horizontally mounted 360° white light with a black low-profile FB base and 0.7m cable, suitable for vessels under 50 meters. It provides 2NM visibility, DNV certification, and consumes 167mA at 12VDC or 110mA at 24VDC, including one navigation light with installation guide.
- Description
- Ask a Question
-
Lopolight 201-012-FB-B - Navigation Light 2NM 360° White, Black W/FB Base
This horizontally mounted 360° navigation light features a black anodized finish with a low-profile FB (flat base) POM mounting system, and includes a 0.7m cable for convenient installation on vessels under 12M, 12-20M, and 20-50M.
- Mounting: Horizontal, FB (flat base) POM system
- Cable: 0.7 meter
- Product number: 201-012-FB-B
- Light color: White
- Dimensions: Ø92.5mm x 36mm (3.6" x 1.4")
- Certification: DNV certified
- Approvals: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
- Visibility range: 2 nautical miles
- Package contents: 1 navigation light, precabled with 0.75m shielded marine-grade cable, installation guide
- Operating temperature: -25°C to 55°C
- Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
- Operating voltage: 10-32VDC
- IP rating: IP68
- Power draw: 2.6W
- Connection: 0.7m cable
- Current consumption: 167mA @12VDC, 110mA @24VDC
- Minimum feed wire gauge: 0.5mm² (AWG22)
- Vessel size: Under 12M, 12-20M, 20-50M
- Weight: 0.42kg (14.66oz)
- EAN: 5704438042797
- UPC: 879343042929
-
